Accuracy
Up to 0.030 mm(1)(0.0012 in)(1)
Volumetric accuracy
(based on part size)
(based on part size)
0.020 mm + 0.060 mm/m(2)(0.0008 in + 0.00072 in/ft)(2)
Volumetric accuracy with MaxSHOT Next™|Elite
0.030 mm + 0.015 mm/m(3)(0.0012 in + 0.00018 in/ft)(3)
Measurement capabilities
(at a working distance of 0.35 m (1,2ft))
(at a working distance of 0.35 m (1,2ft))
Pin1.00 mm (0.0393 in)
Hole1.50 mm (0.0591 in)
Step0.030 mm (0.0012 in)
Wall0.75 mm (0.0295 in)
Measurement resolution
0.025 mm (0.0010 in)
Mesh resolution
0.100 mm (0.0039 in)
Measurement rate
1,200,000 measurements/s
Light source
23 blue laser lines(4)
Scanner Controls
Touchscreen display
Working Distance
250 to 450mm (9.8 x 17.7 in)
Depth of field
200 mm (7.9 in)
Part size range (recommended)
0.05-4 m (0.15-13.1 ft)
Output formats
.dae, .fbx,.iges, .ma, .obj, .ply, .step, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf
Reverse Engineering Software
Scan-to-CAD Pro (included)
Compatible software
3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Metrologic Group (Metrolog X4), New River Kinematics (Spatial Analyzer), Verisurf, Dassault Systèmes (CATIA V5, SOLIDWORKS), PTC (Creo), Siemens (NX, Solid Edge), Autodesk (Inventor, PowerINSPECT)(5)
Weight
920 g (2.0 lb)
Dimensions
(LxWxH)
(LxWxH)
79 x 150 x 304 mm (3.2 x 5.9 x 12 in)
Connection standard
1 X USB 3.0
Operating temperature range
5-40 °C (41-104 °F)
Operating humidity range
(non-condensing)
(non-condensing)
10-90%
Certifications
EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive), compatible with rechargeable batteries (when applicable), IP50, WEEE
Patents
CA 2,600,926, US 7,912,673, CA 2,656,163, EP (FR, UK, DE) 1,877,726, AU 2006222458, US 8,032,327, JP 4,871,352, US 8,140,295, EP (FR, UK, DE) 2,278,271, EP (FR, UK, DE) 2,230,482, IN 266,573, EP (FR, UK, DE) 3,102,908, US 10,271,039, JP 6,596,433, CA 2,938,104, KR 10-2424135, EM 009203334-0001, EM 009203334-0002, EM 009203334-0003, EM 009203334-0004, EM 009203334-0005, EM 009203334-0006, CN 220,206,623 U, CN 308805542 S, CN 221,445,081 U
(1) Typical value for diameter measurement on a calibrated sphere artefact.
(2) Value for spheres spacing measurement on a calibrated length artefact. Results are obtained using integrated photogrammetry with volumetric accuracy optimization.
(3) The volumetric accuracy of the system when using a MaxSHOT 3D cannot be superior to the default accuracy for a given model.
(4) Laser class: 2M (eye safe).
(5) Also compatible with all major metrology, CAD, and computer graphic software through mesh and point cloud import.
